Description
BLUE SEA SYSTEMS C-Series Flat Rocker Circuit Breaker – Single Pole 50A – 7546.
- Rocker actuator is flush in the “ON” position, eliminating the risk of accidential switching
- Color actuator indicates “OFF” position
- Provides overcurrent protection for inverters, bow thrusters, and windlasses
- Combines switching and circuit protection into a single device
- “Trip Free”—cannot be held closed after trip
- Ignition protected—safe for installation aboard gasoline powered boats
Specifications | |
---|---|
Amperage | 50A AC 50A DC |
Actuator Style | Flat Rocker |
Poles | 1 |
Maximum Voltage | 240V AC 48V DC |
Circuit Breaker Type | Magnetic Hydraulic – trip free |
Terminal Stud | 1/4-20 Tin-Plated Brass |
Terminal Stud Torque | 35 in-lb (3.95 Nm) |
Interrupt Capacity | 3000A @ 120V AC 3500A @ 240V AC 5000A @ 32V DC |
Minimum Operating Temperature | -40° C |
Maximum Operating Temperature | 85° C |
Mounting Screw | 6-32 Stainless Steel |
Mounting Screw Torque | 6 in-lb (0.68 Nm) |
Switching Cycles | 10000 |
Weight | 0.55lb (0.25 kg) |
This is a special order item. Most special order items are shipped within 72 hours of ordering, however, some items are not in stock. We will let you know if the item is not available. Alternatively, you may call us at 1-866-473-0420.
