PERKO White 1-1/2 in. Flush-Mount Cockpit Scupper – 285-DP

Description

PERKO White 1-1/2 in. Flush-Mount Cockpit Scupper – 285-DP

The PERKO Figure 0285 cockpit scupper provides a low-profile, corrosion-resistant drain outlet for above-waterline cockpit plumbing. Its removable insert helps block large debris while maintaining the drain path, and the broad flange distributes the installation load across the hull or cockpit surface.

Product Details

• Flush-mount cockpit scupper for above-waterline discharge through a 38.1 mm (1-1/2 in.) hose connection.
• White moulded-polymer construction avoids corrosion and provides a broad 69.9 mm (2-3/4 in.) exterior flange.
• Requires a 47.6 mm (1-7/8 in.) mounting hole and accepts hull thickness up to 44.5 mm (1-3/4 in.).
• The removable insert is designed to stop large objects from entering the drain without materially restricting normal flow.
• PERKO identifies Figure 0326 as the replacement flanged lock-nut family; the correct nut must match the scupper thread.
• Intended for above-waterline cockpit-drain service. Hose-connected through-hulls are not recommended for below-waterline use under ABYC H-27.
• Retail package contains one scupper assembly; hose, clamps and sealant are not included.

Specifications

• PERKO Manufacturer Part Number: 0285DP0WHT
• PERKO Figure / Series: 0285
• Package Format: Retail dealer package – 1 scupper
• Product Type: Flush-mount cockpit scupper
• Application: Above-waterline cockpit discharge
• Material / Colour: White moulded polymer
• Hose Size: 38.1 mm (1-1/2 in.)
• Flange Diameter: 69.9 mm (2-3/4 in.)
• Mounting Hole: 47.6 mm (1-7/8 in.)
• Maximum Hull Thickness: 44.5 mm (1-3/4 in.)
• Inside Diameter: 38.1 mm (1-1/2 in.)
• Replacement Lock Nut: PERKO Figure 0326, matching thread
• Included: Scupper body, insert and lock nut
