GOBIUS SENSOR TECHNOLOGY NMEA 2000 Four-Channel Analog Converter – 970242

Description

GOBIUS SENSOR TECHNOLOGY NMEA 2000 Four-Channel Analog Converter – 970242

The Gobius 970242 converter is the bridge between proven analog sender signals and a modern NMEA 2000 display environment. With up to four input channels, it can consolidate multiple tank senders and make their data available to compatible multifunction displays and vessel monitoring systems.

• Supports up to four analog input channels
• Accepts 0-190 ohm, 240-33 ohm and user-defined 0-999 ohm resistance ranges
• Outputs NMEA 2000/J1939 network messages through a Micro-C connection
• IP67 enclosure and wide -40 C to +85 C operating range suit marine installations
• Can also be applied to compatible engine, pressure or temperature sender data

It is a practical upgrade when you want to keep existing analog sensing hardware but move the information onto a unified NMEA 2000 network.

Specifications

• Channels: Up to 4
• Input signals: 0-190 ohm; 240-33 ohm; user-defined 0-999 ohm
• Network output: NMEA 2000 / J1939 messages
• Operating voltage: 9-16 V DC
• Power consumption: Less than 50 mA
• Connector: Male Micro-C
• Ingress protection: IP67
• Operating temperature: -40 C to +85 C
• Converter size: 90 x 40 x 25 mm
• Device weight: Approximately 115 g
• Cable length: 1 m
