Description
BLUE SEA SYSTEMS 187-Series Circuit Breaker – Surface Mount 200A – 7149.
-
- Combines switching and circuit protection into a single device*
- Clear, single lever operation
- “Trip Free” design cannot be held “ON” during fault current condition
- Waterproof
- Recessed mounting holes for clean appearance
- Large Clearance around terminal studs accept heavy gauge wire lugs
- Robust 5/16 M8 terminals provide high torque connections
- Large lever with vertical/horizontal orientation provides indication of trip status
- Ignition protected – Safe for installation aboard gasoline powered boats
- Meets SAE J1171 external ignition protection requirements
- * Do not use as a switch where high inrush currents are expected.
Specifications | |
---|---|
Amperage | 200A |
Maximum Voltage | 48V DC |
Mounting | Surface Mount |
Circuit Breaker Type | Thermally responsive Bi-metal blade |
Terminal Stud Torque | 75 in-lb (8.47 Nm) |
Interrupt Capacity | 5000A @ 14VDC 3000A @ 28VDC 1500A @ 48VDC |
Minimum Operating Temperature | -40° C |
Maximum Operating Temperature | 85° C |
Case Material | Thermoset Polyester |
Circuit Breaker Class | Type III – switchable/manual reset – trip free |
Mounting Hole | Accept #10 (M5) Screw |
Terminal Stud Size | 5/16″ – 18 |
Weight | 0.58lb (0.26 kg) |
This is a special order item. Most special order items are shipped within 72 hours of ordering, however, some items are not in stock. We will let you know if the item is not available. Alternatively, you may call us at 1-866-473-0420.
