VICTRON ENERGY Orion-Tr Smart 12V/12-30A (360W) Isolated DC-DC Charger – ORI121236120

The VICTRON ENERGY Orion-Tr Smart 12V/12-30A (360W) Isolated DC-DC Charger – ORI121236120 is a highly efficient and intelligent charger designed for a wide range of applications. This isolated DC-DC charger offers a broad input and output voltage range, making it ideal for use in vehicles with smart alternators and systems with extended cable lengths. With Bluetooth Smart connectivity and fully programmable settings, the Orion-Tr Smart charger provides advanced functionality and ease of use.

• Bluetooth Smart enabled: Monitor, change settings, and update the charger using any Bluetooth-enabled device.
• Fully programmable: Configurable battery charge algorithm or fixed output, with smart alternator compatibility.
• Adaptive 3-stage charge algorithm: Bulk, absorption, and float stages for optimal battery management.
• Remote on/off: Allows for easy control with a remote switch or relay contact.
• Parallel operation: Multiple units can be connected in parallel to increase output current.

The Orion-Tr Smart charger is equipped with Bluetooth Smart technology, allowing users to monitor and configure the charger using the VictronConnect app on any Bluetooth-enabled device. This feature provides instant readout of key data, including warnings and alarms, without the need to connect to the product. The charger is fully programmable, offering a configurable battery charge algorithm or a fixed output, and is compatible with smart alternators through its engine running detection mechanism.

The adaptive 3-stage charge algorithm ensures optimal battery management by adjusting the absorption time based on the depth of discharge. For lead-acid batteries, the absorption time is kept short during shallow discharges to prevent overcharging, while it is increased after deep discharges to ensure complete recharging. For lithium batteries, the absorption time is fixed at 2 hours by default. Alternatively, a fixed output voltage can be chosen.

Specifications:

• Input voltage range: 8-17 V
• Under voltage shut down: 7 V
• Under voltage restart: 7.5 V
• Nominal output voltage: 12.2 V
• Output voltage adjust range: 10-15 V
• Output voltage tolerance: +/- 0.2 V
• Output noise: 2 mV rms
• Continuous output current at nominal output voltage and 40°C: 30 A
• Maximum output current (10 s) at nominal output voltage minus 20%: 40 A
• Short circuit output current: 60 A
• Continuous output power at 25°C: 430 W
• Continuous output power at 40°C: 360 W
• Efficiency: 87%
• No load input current: < 80 mA
• Standby current: Less than 1 mA
• Can be used as power supply: Yes, output voltage can be set with Bluetooth
• Galvanic isolation: 200 VDC between input, output, and case
• Operating temperature range: -20 to +55°C (derate 3% per °C above 40°C)
• Humidity: Max. 95% non-condensing
• DC connection: Screw terminals
• Maximum cable cross-section: 16 mm² (AWG6)
• Weight: 1.8 kg (4 lbs)
• Dimensions (hxwxd): 130 x 186 x 80 mm (5.1 x 7.3 x 3.2 inches)
• Protection category: IP43 (electronic components), IP22 (connection area)
• Standards: EN 60950, EN 61000-6-3, EN 55014-1, EN 61000-6-2, EN 61000-6-1, EN 55014-2, ECE R10-5
