SEA-DOG Light-Tip Toggle Switch, SPST On/Off, 15A – 420121-1

Description

SEA-DOG Light-Tip Toggle Switch, SPST On/Off, 15A – 420121-1

The SEA-DOG 420121-1 combines a maintained SPST on/off switch with a lighted toggle tip, making switch status visible without a separate indicator lamp.

• White toggle tip in the OFF position and red tip in the ON position
• SPST maintained On/Off action
• Four blade terminals for switch and illumination connections
• Lever seal and locking ring resist water penetration
• Fits panels up to 1/4" thick through a 15/32" mounting hole

What’s in the Box

• Light-tip toggle switch
• Panel mounting hardware

Specifications

• Part number: 420121-1
• Circuit: SPST
• Action: On/Off
• Terminals: 4 blades
• Rating: 15A at 12V DC
• Mounting hole: 15/32"
• Maximum panel thickness: 1/4"
• Materials: Stamped brass, nylon, and polycarbonate
