PERKO 1-1/2 in. Inlet Check Valve and 5/8 in. Surge Protector Combo – 30-DP0-005

Description

PERKO 1-1/2 in. Inlet Check Valve and 5/8 in. Surge Protector Combo – 30-DP0-005

PERKO part 0030DP0005 is an aftermarket fuel-fill service kit designed to reduce refuelling spitback and wellback. The inlet check valve sits in the fill hose near the tank, while the surge protector sits in the vent line near the fill or tank vent to help the fuel nozzle shut off more predictably and reduce fuel discharge.

Key Features

• Includes both components required to address fill-hose wellback and vent-line spitback
• Sized for standard 38.1 mm (1-1/2 in.) fuel-fill hose and 15.9 mm (5/8 in.) vent hose
• Compatible with plastic or metal fuel tanks
• Allows unobstructed airflow at refuelling rates up to 68.1 L/min (18 US gal/min)
• Usable with EPA-compliant marine fuel systems
• In-hose designs minimize added fittings and potential leak points

Installation and Application

• PERKO states installation should be performed by a qualified marine mechanic
• Fig. 0635 requires at least 50.8 mm (2 in.) of straight fill-hose section and installs small-diameter end first, following the marked flow direction
• Leave at least one hose-clamp width between the clamp and hose end; clamps must sit fully over the barbs/serrations
• Fig. 0553 installs open end first and must remain within 30 degrees of true vertical
• Use ABYC-compliant fuel/vent hose clamping practices and pressure-test for leaks in accordance with ABYC H-24 after installation

Replacement Parts and Compatibility

• Fig. 0635 component: 38.1 mm (1-1/2 in.) fill hose, maximum 68.1 L/min (18 US gal/min)
• Fig. 0553 component: 15.9 mm (5/8 in.) vent hose, maximum 68.1 L/min (18 US gal/min)
• Catalog 320 lists the combination for gasoline or diesel fuel systems; confirm hose sizes, vessel-builder requirements and current installation standards before fitting

Detailed Selection and Service Information

• Catalog 320 describes this as a single combination package containing the Figure 0635 inlet check valve and Figure 0553 surge protector.
• The system is listed for gasoline or diesel installations using 38.1 mm (1-1/2 in.) fill hose and 15.9 mm (5/8 in.) vent hose.
• PERKO states that it can be used with aluminum or plastic tanks, aids automatic nozzle shutoff and permits unobstructed airflow at fill rates up to 68.1 L/min (18 US gal/min).
• The inlet check valve mounts in the fill hose near the tank; the surge protector mounts in the vent line near the fuel fill or tank vent.

What’s in the Box

• 1 PERKO Fig. 0635 in-hose inlet check valve
• 1 PERKO Fig. 0553 in-hose surge protector

Specifications

• PERKO Manufacturer Part Number: 0030DP0005
• False Creek Fuels SKU: PER-30-DP0-005
• Fill-Hose Size: 38.1 mm (1-1/2 in.)
• Vent-Hose Size: 15.9 mm (5/8 in.)
• Maximum Refuelling Rate: 68.1 L/min (18 US gal/min)
• Tank Compatibility: Plastic or metal marine fuel tanks
• Included Inlet Check Valve: PERKO Fig. 0635
• Included Surge Protector: PERKO Fig. 0553
• Surge-Protector Orientation: Within 30° of true vertical
• Post-Installation Test: Pressure test in accordance with ABYC H-24
