Description
Blue Sea Systems Contura Water-Resistant DC Bilge Pump Control Panel – 2 Position – 8664
The Blue Sea Systems Contura Water-Resistant DC Bilge Pump Control Panel – 2 Position is designed for centralized marine electrical distribution and circuit control.
- Consolidated control and circuit protection for up to two bilge pumps
- Designed for 12V or 24V DC systems
- Watertight mounting gasket
- Pre-wired for easier installation
- ON-indicating LEDs embedded in all switches
This panel is intended to support clean, serviceable onboard electrical control. Verify system voltage, branch-circuit ratings, conductor sizes, and installation clearances before installation.
Specifications
- Color: Gray
- Nominal Voltage: 12V DC / 24V DC
- Panel Cumulative Rating: 45A
- Operating Current: 18mA per switch
- Switch Rating: 20A @ 12V DC / 15A @ 24V DC
- Height: 3.75 in (95.25 mm)
- Width: 3.34 in (84.84 mm)
- Depth: 3.00 in (76.2 mm)
- Ingress Protection: IP66
- Component Envelope: Contura mounting component; use product page/drawing for exact panel layout
- Product Dimensions: 16.5 cm L × 5.1 cm W × 3.2 cm H
- Manufacturer: Blue Sea Systems
- Part Number: 8664
