JABSCO HotShot 3 Washdown Pump, 12V, 3 GPM, 50 PSI – 32305-5012-3A

Description

JABSCO HotShot 3 Washdown Pump, 12V, 3 GPM, 50 PSI – 32305-5012-3A

The JABSCO HotShot 3 32305-5012-3A is a compact on-demand washdown pump for rinsing decks, anchors, fish boxes and marine equipment. It combines a 50 PSI pressure switch with dry-running capability and quick-connect plumbing for straightforward installation.

• Open flow of approximately 11.3 L/min / 3 GPM
• 50 PSI / 3.4 bar pressure-switch shut-off
• Self-primes up to approximately 3 m and can run dry without damage
• Includes multiple hose-barb and garden-hose port fittings
• Supplied with an in-line 40-mesh strainer and quick-connect trigger nozzle

Warning: Do not use for gasoline or other flammable liquids. Install with the specified fuse and marine-grade wiring, secure all hoses and relieve pressure before disconnecting the nozzle or servicing the pump.

What’s in the Box

• 1 x HotShot 3 washdown pump
• 2 x 13 mm / 1/2-inch straight hose-barb fittings
• 2 x 19 mm / 3/4-inch straight hose-barb fittings
• 1 x 3/4-inch garden-hose-thread adapter
• 1 x In-line 40-mesh strainer
• 1 x Quick-connect trigger nozzle and adapters

Specifications

• Part Number: 32305-5012-3A
• Voltage: 12V DC
• Open Flow: 11.3 L/min / 3 GPM
• Maximum Pressure: 50 PSI / 3.4 bar
• Maximum Current: Approximately 8 A at 50 PSI
• Recommended Fuse: 15 A
• Maximum Self-Priming Lift: Approximately 3 m
• Ingress Protection: IPX6
