THE APOLLO RA770 STEREO’S PERFECT COMPANION A perfect companion to Apollo RA770, the Fusion Apollo™ MS-SRX400 Marine Zone Stereo – 010-01983-00 combines premium design and superior sound in a compact form factor.
- Custom audio profiles for each zone on your boat to deliver superior quality audio.
- Audio streaming with Wi-Fi technology provides high-quality audio with a faster data transfer rate.
- Experience seamless high-quality audio streaming from your music app via the AirPlay® 2 software feature.
- Enjoy the freedom of musical choice with Fusion PartyBus™-Network technology
- Control your music from a compatible multifunction display (MFD), smart device or Garmin watch.
DESIGNED AND ENGINEERED TO TRUE-MARINE™ STANDARDS
Built on the True-Marine design philosophy from Fusion, the Apollo SRX400 stereo has an IPX6 and IPX7 rated water resistant front panel and has been tested to a high level of protection against salt, fog, temperature, vibration and UV.
MODERN DESIGN AND AESTHETICS
Providing uniformity across the helm, the brilliantly designed black front face blends seamlessly into black glass panels, complementing other electronics and MFDs for a tidy, uniform and elegant installation.
FUSION DIGITAL SIGNAL PROCESSING (DSP)
A technically superior listening experience made simple, Fusion DSP optimizes the audio signal delivered to your Fusion system to produce superior sound quality at all volume levels, in every listening environment.
EASY-TO-INSTALL DSP PROFILES
With a few clicks on your compatible smartphone, setting up your DSP profiles is made simple with the free Fusion-Link™ app. You can set up the preconfigured DSP profiles once and enjoy listening to high-quality audio customized for your ears and the environment.
In a world-first for marine stereos, enjoy the clarity and premium quality of audio streaming with Wi-Fi technology, including the convenience of AirPlay 2 from Apple® and universal plug-and-play.
Designed with Wi-Fi onboard, the Apollo RA770 and its perfect companion SRX400 can be connected without running any wires – reducing installation time, cost and complexity.
OVER-THE-AIR SOFTWARE UPDATES
Updates are now available from your compatible smartphone or device, via the free Fusion-Link app. The Apollo Series is intelligently simple and easy to keep up to date.
Grouping allows you to link up multiple Apollo Series stereos connected to the same network and play the same audio source synchronized across all stereos.
Scroll through available zones on your boat, and enjoy independent volume control, or select ALL volume to adjust a group of stereos at once.
Power options allow you to turn on any connected Apollo Series stereo in standby mode on the Fusion PartyBus™-Network remotely from another Apollo Series stereo.
Home Zone is the physical zone onboard your boat in which the stereo is installed. After adjusting audio in another zone, the stereo defaults to control of the Home Zone after a period of inactivity.
|Physical dimensions||Stereo dimensions (H x W x D): 2.76″ x 4.33″ x 4.81″ (70 x 110 x 122 mm)|
|Weight||12 oz (340 g)|
|Water rating||IPX6 and IPX7 (Front panel only, when properly installed)|
|Power input||10.8-16 VDC|
|Operating temperature range||32° to 122° F (0° to 50° C)|
|Current (max.)||8 A|
|Bluetooth wireless range||Up to 30 ft (10 meters)|
|Wireless frequencies/protocols||Wi-Fi 2.4 GHz @ +15 dBm nominal
Bluetooth 2.4 GHz @ +10 dBm nominal
|Compass-safe distance||3.9″ (100 mm)|
|Display||2.7″ optically bonded color LCD|
|Built-in amplifier||Class-D (2 Ohm stereo-stable)|
|Peak power||140 W|
|Rated power output (2 Ohm)||43 W rms x 2 @ 14.4 V input < 10% THD|
|Rated power output (4 Ohm)||26 W rms x 2 @ 14.4 V input < 10% THD|
|Built-in Digital Signal Processing||yes (with preconfigured DSP profiles)|
|PartyBus™-Network capabilities||yes (wired or wireless)|
|Fusion-Link™ control||yes (with MFD and smartphone)|
|Multi-Zone™ technology||1 zone|
|Bluetooth wireless technology||yes|
|Multi-language interface||Bulgarian / Chinese (Simplified) / Chinese (Traditional) / Croatian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Italian / Japanese / Korean / Norwegian / Polish / Portuguese (BR) / Portuguese (PT) / Slovenian / Spanish / Swedish / Thai / Turkish|
|Software updates||Over-the-air software updates via the Fusion-Link app|
|Sources||AM / FM / Bluetooth / Apple AirPlay 2 / UPnP|
|Ethernet||One Ethernet port|
|AM/FM radio||One Motorola antenna connector port|
|Speaker||2 x speaker connections (1 zone amplified)|
|RCA Pre-out (left, right and subwoofer)||1 zone (requires external amplification)|
|Line out||1 (1 x L + R per zone, requires external amplification)|
|Subwoofer out||1 x mono output (requires external amplification)|
- Important Safety and Product Information
- Installation Instructions
- Flush Mount Template
- Owner’s Manual
