Blue Sea Systems AC 3-Position Distribution Panel – 8058

Description

Blue Sea Systems AC 3-Position Distribution Panel – 8058

The Blue Sea Systems AC 3-Position Distribution Panel is designed for marine and mobile electrical circuit protection.

• Hot, neutral, and safety-ground buses installed and fully pre-wired
• Circuit label positions are backlit; no separate backlight kit required
• ON-indicating LEDs installed in all circuit positions
• Maximum panel amperage of 100A
• Positions: 3

For best results, match the fuse or breaker rating to the protected conductor and load, and confirm voltage, interrupt rating, mounting clearance, and terminal requirements before installation.

Specifications

• Positions: 3
• Nominal Voltage: 120V AC
• Maximum Amperage: 100A
• Height: 3.75 in (95.25 mm)
• Width: 5.25 in (133.35 mm)
• Manufacturer: Blue Sea Systems
• Part Number: 8058
