Description
The Victron Orion XS 12V 50A DC-DC charger is a next-generation solution for charging your auxiliary battery bank safely and efficiently from your alternator or starter battery. Designed with Victron’s advanced adaptive charging technology, it ensures optimal battery performance and long life, even under demanding conditions. Compact, lightweight, and fully protected, the Orion XS is built for marine, RV, and off-grid power systems where reliability and smart charging are essential.
- High-efficiency DC-DC charging with up to 50A output at 12V
- Fully programmable charging profiles, including support for lithium batteries
- Smart alternator compatibility (Euro 5/6 vehicles) with engine running detection
- Bluetooth Smart built in for setup, monitoring, and firmware updates via the VictronConnect app
- Robust, fanless design with full electronic protection against overload, overheating, and short circuit
The Orion XS 12|50-50 integrates seamlessly into your electrical system, offering precise and adaptive multi-stage charging to match your battery chemistry. Its fanless aluminum housing ensures silent operation while maximizing heat dissipation for long-term durability. With built-in Bluetooth, configuration is simple and intuitive, allowing you to fine-tune charging parameters directly from your phone or tablet. Whether for boats, campervans, or off-grid installations, this charger delivers the dependable power management needed for modern energy systems.
Specifications
- Model: Orion XS 12|50-50 (DC-DC Battery Charger)
- Input voltage range: 8–17V
- Nominal output voltage: 12.2–15V (adjustable)
- Continuous output current: 50A
- Input current limit: 55A (adjustable)
- Maximum efficiency: 98%
- Operating temperature range: –40°C to +60°C (full power up to 40°C, derating thereafter)
- Protection: Over-temperature, overload, short circuit, reverse polarity
- Communication: Bluetooth Smart, VE.Direct port
- Cooling: Natural convection (fanless design)
- Dimensions: 184 x 157 x 80 mm
- Weight: 1.8 kg
- Ingress protection: IP65
