SEA-DOG 2-3/4″ x 1-1/2″ Offset Short-Side Door Hinge Pair – 201570-1

Description

SEA-DOG 2-3/4" x 1-1/2" Offset Short-Side Door Hinge Pair – 201570-1

The SEA-DOG 201570-1 is a 2-3/4" x 1-1/2" offset short-side door hinge pair designed for raised doors that need the pivot point moved outward to gain opening clearance. Its geometry and mounting pattern are specific to this hinge style, so it should be matched to the door, lid, hatch, or ladder arrangement before drilling.

• Stamped 304 stainless steel construction
• Published open footprint approximately 69.8 x 38.1 mm
• Five #8 flat-head fasteners per hinge; not included
• Surface-mount design for the front of a raised door
• 9.5 mm offset moves the pivot point away from the frame
• Supplied as a matched pair

What’s in the Box

• 2 hinges

Specifications

• Manufacturer: SEA-DOG
• Part Number: 201570-1
• Product Type: 2-3/4" x 1-1/2" Offset Short-Side Door Hinge
• Material: Stamped 304 stainless steel
• Open Footprint: 69.8 x 38.1 mm
• Material Thickness: 1.6 mm
• Fasteners: Five #8 flat-head fasteners per hinge; not included
• Quantity: 2 hinges
• Offset: 9.5 mm (3/8 in)
