SEA-DOG Anchor Swivel, 316 Stainless Steel, for 5/16″-1/2″ Chain – 182612-1

Description

SEA-DOG Anchor Swivel, 316 Stainless Steel, for 5/16"-1/2" Chain – 182612-1

A low-profile 316 stainless-steel anchor swivel for 5/16"-1/2" chain, designed to rotate between the anchor and rode while passing smoothly over compatible bow rollers.

• Compatible chain sizes: 5/16"-1/2"
• Double locking pins provide additional security
• Streamlined profile helps reduce snagging at the bow roller
• Can be installed between anchor and chain or between chain and line
• Investment-cast AISI 316 stainless steel construction

Important: Breaking strength is not a working load limit. Coat the pin threads with blue threadlocker or anti-seize as specified by SEA-DOG; the 4 mm hex wrench is not included.

What’s in the Box

One anchor swivel.

Specifications

• Compatible chain sizes: 5/16"-1/2"
• Dimension A: 4-11/16"
• Dimension B: 13/16"
• Dimension C: 1-1/16"
• Dimension D: 9/16"
• Dimension E: 1-5/8"
• Manufacturer-published breaking strength: 17,000 lb
• Material: Investment-cast AISI 316 stainless steel
• Manufacturer item weight: 1.17 lb
• Part number: 182612-1
