SEA-DOG 316 Stainless Steel 45° Rectangular Rail Base for 7/8 in Tubing, 1-11/16 x 3 in – 281450-1

Description

SEA-DOG 316 Stainless Steel 45° Rectangular Rail Base for 7/8 in Tubing, 1-11/16 x 3 in – 281450-1

The SEA-DOG 316 Stainless Steel 45° Rectangular Rail Base for 7/8 in Tubing, 1-11/16 x 3 in anchors 7/8 in handrail tubing to a deck or other flat mounting surface at a fixed 45° angle. Its rectangular base distributes the mounting load and the tube socket is secured with set screws after the rail is aligned.

• Holds 7/8 in outside-diameter handrail tubing at 45°
• Rectangular mounting base: 1-11/16 x 3 in
• Installs with four #10 FH fasteners (not included)
• Includes tube-retaining set screws where applicable
• Investment-cast 316 stainless steel for corrosion resistance

What’s in the Box

• One 45° rectangular rail base
• Tube-retaining set screw(s), where applicable

Specifications

• Product type: 45° Rectangular Rail Base
• Tube outside diameter: 7/8 in
• Rail angle: 45°
• Base size: 1-11/16 x 3 in
• Mounting fasteners: Four #10 FH, not included
• Material: Investment-cast 316 stainless steel
• Recommended tube wall: 0.049 in
