PERKO Chrome-Plated Reverse-Bevel Rim Lock Set with Flush Strike – 919-DP-CHR

Description

PERKO Chrome-Plated Reverse-Bevel Rim Lock Set with Flush Strike – 919-DP-CHR

This PERKO rim lock mounts on the door surface and provides a finished lever-handle set for marine interiors. The reverse bevel latch orientation and flush strike are selected for the specified door swing and frame arrangement.

Product Details

• Chrome-plated zinc-alloy case, escutcheon and operating hardware.
• Configured with a reverse bevel latch and flush strike.
• Locks by inside turn button or outside key.
• Designed for doors 15.9 to 34.9 mm (5/8 to 1-3/8 in.) thick.
• Escutcheon measures 111.1 x 31.8 mm (4-3/8 x 1-1/4 in.).
• Replacement knob and handle assembly: 0962000CHR.
• Replacement regular-bevel cam: 0984000CHR; reverse-bevel cam: 0920DP0CHR.
• Replacement flush strike: 0913DP0CHR.
• Replacement escutcheon plate with keys: 0953000CHR.

Specifications

• PERKO Manufacturer Part Number: 0919DP0CHR
• Product Type: Reverse-Bevel Rim Lock Set with Flush Strike
• Material: Zinc alloy
• Finish: Chrome plated
• Bevel: Reverse Bevel
• Strike Type: Flush Strike
• Case Dimensions: 98.4 x 50.8 mm (3-7/8 x 2 in.)
• Escutcheon Dimensions: 111.1 x 31.8 mm (4-3/8 x 1-1/4 in.)
• Compatible Door Thickness: 15.9 to 34.9 mm (5/8 to 1-3/8 in.)
• Mounting Fasteners: #6 screws
• Replacement Knob and Handle: 0962000CHR
• Replacement Strike: 0913DP0CHR
