PERKO 32V 10W Double-Contact Bayonet Indexing Navigation Light Bulb – 375-32V-10W

Description

PERKO 32V 10W Double-Contact Bayonet Indexing Navigation Light Bulb – 375-32V-10W

This indexed double-contact bayonet lamp is intended for PERKO navigation lights designed and marked for 32-volt, 10-watt operation. The indexing pins position the bulb correctly in the specified socket.

Product Details

• Clear 32V navigation-light replacement bulb with a double-contact bayonet indexing base.
• Rated at 10W with an approximate current draw of 0.31A.
• Offset/indexed bayonet pins prevent installation in a non-matching standard bayonet socket.
• Use only in a fixture whose identification plate or PERKO service information specifies the 32V 10W lamp.
• Correct bulb wattage is essential for certified visibility; higher- or lower-wattage substitutes can alter output and heat load.
• PERKO directs customers to confirm 32V applications with the factory where current catalog listings do not show the complete 32V configuration.

Specifications

• PERKO Manufacturer Part Number: 037532V10W
• Product Type: Navigation-light replacement bulb
• Nominal Voltage: 32V DC
• Power: 10W
• Current Draw: Approximately 0.31A
• Base: Double-contact bayonet indexing base
• Glass: Clear
