PERKO Black 12V Surface-Mount Utility Light with Diffused Cover – 137-DP-BLK

Description

PERKO Black 12V Surface-Mount Utility Light with Diffused Cover – 137-DP-BLK

PERKO part 0137DP0BLK is a compact surface-mount courtesy and utility light for steps, lockers, cabinets and other small marine spaces. Its diffused cover softens the output and spreads the light over the mounting area. Catalog 320 identifies Figure 0137 as a conventional 12V bulb fixture; the separate Figure 0145 is the LED model with a shielded cover.

Key Features

• Complete 12V utility-light fixture with bulb included
• Diffused cover distributes light and reduces a harsh point-source appearance
• Black molded-polymer housing resists corrosion and keeps the fixture compact
• Low published load of 1W and 0.08A
• Small surface-mount footprint for steps, lockers, cabinets and console interiors

Installation and Application

• Surface mount using #6 fasteners appropriate for the substrate
• Connect to a fused 12V DC lighting circuit and verify the fixture is protected from mechanical damage
• Orient the diffused cover to illuminate the intended surface without direct glare at the helm
• Do not order this part when the integrated-LED Figure 0145 model is required

Detailed Selection and Service Information

• Catalog correction: Figure 0137 is an incandescent 12V surface-mount utility light with a bulb included; it is not the Figure 0145 LED model.
• The molded-polymer fixture uses a diffused cover and measures 47.6 x 14.3 mm (1-7/8 x 9/16 in.).
• Published rating is 1W and 0.08A with #6 mounting screws; OEM bulk equivalent is 0137000BLK.

What’s in the Box

• 1 black surface-mount utility-light fixture
• 1 installed 12V bulb

Specifications

• PERKO Manufacturer Part Number: 0137DP0BLK
• False Creek Fuels SKU: PER-137-DP-BLK
• Figure: 0137
• Light Type: Incandescent surface-mount utility light
• Cover: Diffused
• Housing: Black molded polymer
• Voltage: 12V DC
• Power: 1W
• Current Draw: 0.08A
• Overall Size: 47.6 x 14.3 mm (1-7/8 x 9/16 in.)
• Fastener Size: #6
• Bulb Included: Yes
• OEM Bulk Package: 0137000BLK
