VICTRON ENERGY MultiPlus-II 2x120V Inverter/Charger 24V 3000VA 70A 50A Transfer – PMP242305132

Description

VICTRON ENERGY MultiPlus-II 2x120V Inverter/Charger 24V 3000VA 70A 50A Transfer – PMP242305132

The Victron Energy MultiPlus-II 24/3000/70-50 2x120V is a powerful inverter/charger designed for standard North American 50A 120/240V split-phase power systems. It combines a pure sine wave inverter, adaptive battery charger, and high-speed AC transfer switch in one unit, making it a strong choice for marine, RV, van, cabin, backup, and off-grid electrical systems.

When connected to shore power or a generator, the MultiPlus-II 2x120V can accept and pass through both lines of a 120/240V supply. When only a single-phase 120V source is available, the unit can provide 120V output on both lines. In inverter mode, it supplies 120V single-phase power to both sides of the distribution panel, while 240V loads are only supported when a true split-phase 120/240V AC source is present.

• 24V 3000VA MultiPlus-II inverter/charger for North American 2x120V systems
• 70A adaptive battery charger with 50A AC transfer switch
• PowerControl and PowerAssist help manage limited shore power or generator capacity
• Two AC outputs, with the second output live only when external AC power is available
• VE.Bus communication supports monitoring, system integration, parallel operation, and three-phase configurations

The MultiPlus-II 2x120V is suitable for LiFePO4 and other battery technologies and can be configured, monitored, and integrated using compatible Victron equipment such as Cerbo GX, Ekrano GX, Digital Multi Control, MK3-USB interface, VE.Bus Smart Dongle, and VRM remote monitoring.

Specifications

• Brand: Victron Energy
• Part Number: PMP242305132
• GTIN/EAN: 08719076059219
• Product Type: Inverter/charger
• Model: MultiPlus-II 24/3000/70-50 2x120V UL
• Battery Voltage: 24V DC
• DC Input Voltage Range: 19 – 33V DC
• Inverter Output Voltage: 120V AC ± 2%
• Output Frequency: 60 Hz ± 0.1%
• Continuous Output Power at 25°C: 3000VA / 2400W
• Continuous Output Power at 40°C: 2200W
• Continuous Output Power at 65°C: 1700W
• Peak Power: 5500W
• Maximum Efficiency: 94%
• Battery Charge Current: 70A
• Transfer Switch: 50A
• Maximum AC Input Current: 50A per leg
• AC Input: Split phase 180 – 280V AC or single phase 90 – 140V AC, 45 – 65 Hz
• AC Output Configuration: 2x120V; 120/240V pass-through when supplied by split-phase AC source
• PowerControl and PowerAssist: Yes, on L1 input
• VE.Bus Communication: Yes
• Remote On/Off: Yes
• Programmable Relay: Yes
• General Purpose Communication Ports: 2
• Battery Temperature Sensor: Yes
• Protection Category: IP22
• Operating Temperature Range: -40°C to +65°C
• Enclosure Material/Colour: Steel, blue RAL 5012
• Battery Connection: 2 M8 bolts
• AC Connection: Screw terminals, 21 mm² / 4 AWG
• Approximate Dimensions: 578 mm H x 275 mm W x 148 mm D
• Approximate Weight: 22 kg / 48 lb
• Safety Standard: UL 458
