ACR Electronics RCL-100 LED White 12/24V Searchlight with URP-103 Point Pad – 1978

Description

ACR Electronics RCL-100 LED White 12/24V Searchlight with URP-103 Point Pad – 1978

The ACR Electronics RCL-100 LED is a rugged remote-controlled searchlight for sport yachts, fishing vessels and commercial marine applications. Part 1978 is the white wired-control kit supplied with the URC-104 master controller and URP-103 Point Pad, without the handheld URH-103 wireless remote.

• Nine-LED array delivers 220,000 peak candela through a concentrated long-range spot beam.
• Continuous 360-degree horizontal rotation and two movement speeds support rapid scanning and precise aiming.
• Elevation range extends 9 degrees above and 17 degrees below the mounting plane.
• XRCiZ automatic exercise periodically moves the searchlight to help maintain gears, bearings and contacts.
• Marine-grade die-cast aluminum housing, glass lens and enclosed elevation mechanism support exposed installation.
• Includes the URC-104 master controller, URP-103 wired Point Pad and 4.57 m harness.

Specifications

• Housing color: White
• Input voltage: 12/24V DC
• Light source: Nine-LED array
• Peak beam intensity: 220,000 candela
• Beam pattern: Approximately 7-degree horizontal spot
• Horizontal rotation: Continuous 360 degrees
• Elevation: 9 degrees up and 17 degrees down
• Controls included: URC-104 master controller and URP-103 wired Point Pad
• Wireless handheld remote: Not included with part 1978
• Harness length: 4.57 m
• Maximum current: Approximately 3.5A
• LED service life: More than 40,000 hours
• Housing material: Die-cast aluminum alloy
• Product dimensions: 20.3 x 22.9 x 20.3 cm
• Product weight: Approximately 3.2 kg
• Manufacturer part number: 1978

Important: Shipping fields are manufacturer carton values. Part 1978 is the wired Point Pad configuration and should not be described as including the handheld wireless remote.
