Description
ZIPWAKE IT300-S PRO Chine Starboard Interceptor with 3m Cable – 2021703
The Zipwake IT300-S PRO CHINE Starboard is a Series S PRO interceptor for high-speed automatic trim and motion-control installations. Its chine – starboard geometry is intended for the corresponding transom location or hull shape, while the fast electric servo drives a 30 mm blade stroke for responsive pitch and roll corrections.
- 300 mm Series S PRO interceptor in chine – starboard configuration for model-specific transom installation.
- Fast 30 mm blade stroke at up to 100 mm/s supports rapid trim and roll corrections.
- Rated by Zipwake for vessels operating up to 60 knots when correctly selected and installed.
- IP68-rated interceptor/servo architecture is designed for submerged marine service.
- Supplied with a 3 m PUR cable and cable cover; cable can be extended within Zipwake system limits.
This is an individual interceptor component for the Zipwake PRO ecosystem, not a complete standalone trim system. Match port/starboard, chine, V-shaped, intermediate or straight geometry to the vessel and existing system before ordering.
Specifications:
- Manufacturer: Zipwake
- Model: IT300-S PRO CHINE Starboard
- Part Number: 2021703
- Series: Series S PRO
- Geometry: Chine – starboard
- Nominal Length: 300 mm
- Product Weight: 2.2 kg
- Servo: SU-S PRO
- Maximum Boat Speed: 60 knots
- Blade Stroke: 30 mm
- Blade Rate: 100 mm/s
- Servo Supply: 36V DC
- Maximum Servo Power: 35W
- Waterproof Rating: IP68 to 5 m
- Cable: 3 m PUR, M12 5-pin; cable cover included
