JABSCO PAR-Max 3 Automatic Freshwater Pump, 12V, 3 GPM, 40 PSI – 31395-4012-3A

Description

JABSCO PAR-Max 3 Automatic Freshwater Pump, 12V, 3 GPM, 40 PSI – 31395-4012-3A

JABSCO PAR-Max 3 Automatic Freshwater Pump, 12V, 3 GPM, 40 PSI – 31395-4012-3A is an automatic marine freshwater delivery pump from JABSCO’s PAR-Max family, rated for 3 GPM (11 L/min) open flow at 12 VDC with a 40 PSI (2.8 bar) shut-off pressure. The integrated sealed pressure switch provides on-demand operation, while the built-in bypass reduces rapid cycling and helps smooth flow. Its compact standard-duty motor housing is designed for economical installations where dependable on-demand freshwater delivery is required.

• Automatic on-demand operation with integrated sealed pressure switch
• Co-molded TPV diaphragm and EPDM check valves for durable freshwater service
• Self-priming to at least 7 ft (2.13 m) and capable of running dry without damage
• Quick-connect plumbing ports and vibration-dampening mounting feet simplify installation and service
• IPX6 ingress protection; CE, ISO 8846 and RCM certifications listed by JABSCO/Xylem

Specifications

• Manufacturer: JABSCO / Xylem
• MPN: 31395-4012-3A
• Series: PAR-Max 3
• Voltage: 12 VDC
• Open Flow: 3 GPM (11 L/min)
• Shut-Off Pressure: 40 PSI (2.8 bar)
• Maximum Current: 6.2 A
• Recommended Fuse: 10 A
• Port Fittings: 2 x 1/2 in straight hosebarbs
• Strainer: Inline 40-mesh quick-connect strainer
• Motor: Brushed permanent-magnet TENV
• Pump-Head Upper Housing: Glass-fiber-reinforced polypropylene
• Diaphragm: Co-molded TPV
• Check Valves: EPDM
• Maximum Inlet Pressure: 30 PSI (2.1 bar)
• Fluid Temperature Range: 32°F to 140°F (0°C to 60°C)
• Dry Self-Priming Capability: Minimum 7 ft (2.13 m)
• Ingress Protection: IPX6
• Overall Dimensions: 9.1 x 4.2 x 4.2 in (23.1 x 10.7 x 10.7 cm)
• Mounting-Hole Centres: 2.3 x 3.2 in (5.8 x 8.1 cm)

What’s in the Box

• 1 x JABSCO PAR-Max 3 freshwater delivery pump
• 2 x 1/2 in straight hosebarbs
• Inline 40-mesh quick-connect strainer
