JABSCO Shower Drain and Bilge Diaphragm Pump, 24V, 16 L/min – 50880-1100

Description

JABSCO Shower Drain and Bilge Diaphragm Pump, 24V, 16 L/min – 50880-1100

The JABSCO 50880-1100 is a compact 24V DC single-diaphragm pump for shower-drain, grey-water and selected bilge duties. Its filterless flow path, dry-running capability and multi-position port arrangement simplify installation where hair and small debris may be present.

• Maximum flow approximately 16 L/min
• Self-priming to approximately 3 m vertical lift
• 19 mm hose connections
• Can run dry without immediate damage
• Filterless single-diaphragm design with multi-position ports

Warning: Confirm voltage, port size, rotation and application before installation. Disconnect electrical power and close associated valves before service. Do not use for petrol, solvents or liquids with a flash point below 37°C unless the pump is specifically approved for that service.

What’s in the Box

• 1 x JABSCO 50880-1100 diaphragm pump
• Rubber mounting feet and ports as supplied

Specifications

• Part Number: 50880-1100
• Voltage: 24V DC
• Maximum Flow: Approximately 16 L/min / 4.2 GPM
• Self-Priming Lift: Up to approximately 3 m
• Connections: 19 mm hose
• Recommended Fuse: 5A
• Applications: Shower drain, grey water and suitable bilge service
