Description
HARKEN T29mm Triple Bullet Block — Becket – 087
HARKEN T29mm Triple Bullet Block — Becket – 087 is a Harken Carbo-family block built for efficient line handling with a high strength-to-weight ratio and low-friction operation.
- High-strength composite soft-attach construction eliminates a conventional metal shackle.
- Free-running bearing geometry is designed for quick trim and controlled easing.
- Attachment line routes through the block head for a light, adaptable installation.
- Configuration is purpose-built around the listed sheave, attachment and becket/cam arrangement.
- UV-resistant marine materials are selected for dependable deck service.
Low-friction Bullet blocks lead control lines aft. They are compact and lightweight, with fast trim and release under high or low loads.
For best results, confirm the Harken part number and system compatibility before installation, and operate the hardware within Harken’s published line-size and load limits.
Specifications
- Manufacturer: Harken
- Part Number: 087
- Series / Family: T2
- Nominal Size: 29 mm
- Configuration: Triple, Becket
- Construction: Fiber-reinforced composite / Carbo family
- Sheave Ø (mm): 29 mm
- Sheave Ø (in): 1 1/8 in
- Length (mm): 95 mm
- Length (in): 3 3/4 in
- Weight (g): 128 g
- Weight (oz): 4.5 oz
- Shackle pin Ø (mm): 5 mm
- Shackle pin Ø (in): 3/16 in
- Maximum line Ø (mm): 8 mm
- Maximum line Ø (in): 5/16 in
- Maximum working load (kg): 272 kg
- Maximum working load (lb): 600 lb
- Breaking load (kg): 907 kg
- Breaking load (lb): 2000 lb
