Description
The Racor S3227 is a Spin-on Series Marine Replacement Cartridge Filter Element, compatible with Racor’s 320R-RAC-01 Filter Assembly fuel filter / water separator assembly. The elements exhibit exceptional removal efficiency of both bulk and emulsified water, low restriction of fuel flow, and high dirt-holding capacity. Their unique design makes them capable of performing in modern marine diesel and gasoline applications, where harsh conditions can cause tiny particles of dirt and water to score and erode precision components, leading to engine damage and increased downtime.
The filter body is protected with a durable electrostatically-applied powder coating for superior corrosion resistance. The spin-on filter design is simple to service and features a reusable clear engineering plastic or metal contaminant collection bowl with a self-venting drain for draining out collected contaminants and water.
All Spin-on Series marine replacement cartridge filter elements utilize Racor’s high-efficiency Aquabloc® engineered media. Aquabloc® is a blend of high-grade cellulose compounded with resins and a special chemical treatment. It incorporates pleat-spacing corrugations and a graduated pore structure to increase dirt-holding capacity and extend filter life. The media is waterproof and rustproof, capturing contaminants while the specially treated surface separates and coalesces water from the fuel, which causes the water to gather into large droplets that then fall into the fuel filter’s collection bowl.
Racor S3227 Specifications:
- PRODUCT TYPE FILTER: MARINE GASOLINE
- DESCRIPTION: Replacement Fuel Filter/Water Separator
- MAXIMUM FLOW RATE: 60 GPH (227 LPH)
- FILTER RATING: 10 Micron
- PORT/CONNECTION SIZE: 1″-14 Center Thread
- ADDITIONAL DETAIL: For 320R-RAC-01 Filter Assembly
- COLLECTION BOWL: RK30475
